Material ID: 3RK1301-0BB00-0AA2

DS1-X for ET 200S Standard DOL Starter

The DS1-X is an expandable DOL starter designed for the ET 200S system. It has a setting range of 0.14...0.2 A, AC-3, and can handle up to 0.06 kW / 400 V. This electromechanical starter is specifically designed for brake control module applications.

ET 200S Distributed I/O

The ET 200S distributed I/O system has been superseded by the new ET 200SP system. It provides a reliable and efficient solution for distributed input/output applications.

Technical Features:

Commercial Benefits:

    • Expandable DOL starter
    • Setting range: 0.14...0.2 A, AC-3
    • Power rating: up to 0.06 kW / 400 V
    • Electromechanical starter
    • Designed for brake control module applications
    • Reliable and efficient solution for distributed input/output applications
    • Superseded by the new ET 200SP system
Additional Information

Support

Technical Data

Manuals / Links

Thông số kỹ thuật
FEATUREVALUE

Voltage type for actuatingDC
Rated control supply voltage DC28.8 V
Degree of protection (IP)IP20
Rated operation power at AC-3, 400 V0.06 kW
Type of electrical connection of main circuitScrew connection
Rated operation current at AC-3, 400 V0.2 A
Width45 mm
Overload release current setting0.14 A
With transformerfalse
Rated control supply voltage DC20.4 V
With short-circuit releasetrue
Height265 mm
Supporting protocol for ASIfalse
Type of motor starterDirect online starter (DOL)
Overload release current setting0.2 A
Depth120 mm
Release classCLASS 10
