Material ID: 6AG1055-1FB00-7BA2
- SIPLUS LOGO! DM8 230V based on 6ED1055-1FB00-0BA2 with conformal coating, -40…+70 °C, start up -25 °C, expansion module, power supply / I/O: 230 V/230 V/relay, 2 MW, 4 DI/4 DQ for LOGO! 8
- The LOGO! expansion modules enable a LOGO! configuration to be expanded in a very inpidual way.
- A LOGO! 8 basic unit can be expanded to 24 digital inputs, 20 digital outputs, 8 analog inputs and 8 analog outputs.
- For this purpose, ten different expansion modules are available which allow expansion with digital and analog inputs and outputs using different input voltages.
- SIPLUS extreme is the ideal solution if your automation system components are exposed to fluctuating temperatures, high humidity, even condensation and frost.
- Thus, you can be sure that reliable functionality is guaranteed.
Additional Information
Support | Technical Data | Manuals / Links |
Thông số kỹ thuật
| FEATURE | VALUE |
| Input current at signal 1 | 0.37 mA |
| Supply voltage AC 60 Hz | 265 V |
| Supply voltage DC | 253 V |
| Voltage type (supply voltage) | AC/DC |
| Digital outputs configurable | true |
| Explosion safety category for dust | None |
| Supply voltage AC 50 Hz | 85 V |
| Width | 35.5 mm |
| Height | 90 mm |
| Supply voltage AC 50 Hz | 265 V |
| Depth | 58 mm |
| Short-circuit protection, outputs available | false |
| Number of digital inputs | 4 |
| Supply voltage AC 60 Hz | 85 V |
| Time delay at signal change | 1.5 ms |
| Type of output voltage | AC/DC |
| Output current | 5 A |
| Digital inputs configurable | true |
| Type of digital output | Relay |
| Redundancy | false |
| Permitted voltage at output | 0 V |
| Appendant operation agent (Ex ib) | false |
| Appendant operation agent (Ex ia) | false |
| Permitted voltage at input | 265 V |
| Permitted voltage at input | 0 V |
| Suitable for safety functions | false |
| Permitted voltage at output | 265 V |
| Number of digital outputs | 4 |
| Type of voltage (input voltage) | AC/DC |
| Supply voltage DC | 100 V |
