Material ID: 6AG1131-4BD01-2AA0

SIPLUS ET 200S EM 4DI (1 PU=5 units)

The SIPLUS ET 200S EM 4DI is an electronic module with a width of 15 mm and operates on a 24 V DC power supply. It comes in a packing unit of 5 units, with 1 packing unit containing 5 modules.

This module, based on 6ES7131-4BD01-0AA0, is designed to operate in a temperature range of -25°C to +60°C. It is equipped with conformal coating, which provides protection against biologically, chemically, and physically active substances, condensation, frost, and corrosive gases.

SIMATIC ET 200S

SIMATIC ET 200S is a modularly scalable, distributed I/O system that is specially designed for installation in small control boxes near the machine. It offers the flexibility to be directly plugged into an ET 200S IM with CPU functionality or connected to a central controller via PROFINET or PROFIBUS.

The system supports up to 64 I/O modules, which can be inserted in any combination. It provides a comprehensive range of modules, including standard functions (ST) as well as modules with extended functions and diagnostics (HF High Feature/HS High Speed) for improved scalability in terms of functionality and price.

One of the advantages of the ET 200S system is its ease of application. Modules and terminal boxes can be swapped during operation, allowing for increased availability and productivity of the machine. This feature, known as "hot swapping," ensures that the system remains operational even during maintenance or replacement of modules.

In addition to the CPU, the digital input modules of the ET 200S system are also protected against extreme ambient conditions. The 100% conformal coating ensures reliable operation in various environments, regardless of the conditions.

With the SIPLUS ET 200S EM 4DI module, your digital signals are reliably recorded, ensuring the overall performance and functionality of your machine.

    Additional Information

    Support

    Technical Data

    Manuals / Links

    Thông số kỹ thuật
    FEATUREVALUE
    Supporting protocol for AS-Interface Safety at Workfalse
    Width15 mm
    Digital inputs configurabletrue
    Supply voltage DC28.8 V
    Supporting protocol for INTERBUS-Safetyfalse
    Voltage type (supply voltage)DC
    Front built-in possiblefalse
    Appendant operation agent (Ex ib)false
    Radio standard Bluetoothfalse
    Rail mounting possibletrue
    Radio standard GSMfalse
    Number of HW-interfaces RS-2320
    Supporting protocol for DeviceNet Safetyfalse
    Supporting protocol for PROFINET IOfalse
    Degree of protection (IP)IP20
    Number of HW-interfaces RS-4220
    Fieldbus connection over separate bus coupler possibletrue
    Number of interfaces PROFINET0
    Suitable for safety functionsfalse
    Supporting protocol for Data-Highwayfalse
    Supporting protocol for TCP/IPfalse
    Supporting protocol for Modbusfalse
    Number of digital inputs4
    Supporting protocol for PROFIBUSfalse
    Type of digital outputNone
    Number of HW-interfaces parallel0
    Rack-assembly possiblefalse
    Supporting protocol for ASIfalse
    Type of voltage (input voltage)DC
    Radio standard UMTSfalse
    Time delay at signal change2 ms
    Supporting protocol for KNXfalse
    Appendant operation agent (Ex ia)false
    Number of HW-interfaces USB0
    Supporting protocol for SafetyBUS pfalse
    Number of HW-interfaces industrial Ethernet0
    Wall mounting/direct mountingfalse
    Supporting protocol for SERCOSfalse
    Radio standard WLAN 802.11false
    Number of HW-interfaces RS-4850
    Height81 mm
    Supporting protocol for PROFIsafefalse
    Supporting protocol for PROFINET CBAfalse
    Permitted voltage at input30 V
    Time delay at signal change4.5 ms
    Supporting protocol for SUCONETfalse
    Supporting protocol for DeviceNetfalse
    Radio standard GPRSfalse
    Supply voltage DC20.4 V
    IO link masterfalse
    With optical interfacefalse
    Number of HW-interfaces serial TTY0
    Supporting protocol for other bus systemsfalse
    Depth52 mm
    Permitted voltage at input-30 V
    Input current at signal 17 mA
    Supporting protocol for INTERBUSfalse
    System accessorytrue
    Supporting protocol for LONfalse
    Supporting protocol for Foundation Fieldbusfalse
    Number of HW-interfaces other0
    Number of digital outputs0
    Number of HW-interfaces wireless0
    Supporting protocol for CANfalse
    Supporting protocol for EtherNet/IPfalse
