Material ID: 6AG1131-4BD01-7AB0

SIPLUS ET 200S EM 4DI HF

SIPLUS ET 200S EM 4DI HF is a modularly scalable, distributed I/O system designed for installation in small control boxes near the machine. It is based on 6ES7131-4BD01-0AB0 and comes with conformal coating, allowing it to operate in temperatures ranging from -25°C to +70°C.

Technical Features:

Commercial Benefits:

With SIPLUS ET 200S EM 4DI HF, you can benefit from a flexible and reliable I/O system that can withstand harsh environmental conditions while providing excellent performance and scalability.

    • Modularity: The system can be expanded with up to 64 I/O modules, which can be inserted in any combination.
    • Functionality: The system offers a comprehensive range of modules, including modules with standard functions (ST) and modules with an extended range of functions and diagnostics (HF High Feature/ HS High Speed).
    • Connectivity: The modules can be plugged directly into an ET 200S IM with CPU functionality or connected to a central controller via PROFINET or PROFIBUS.
    • Hot Swapping: The system supports "hot swapping," allowing modules and terminal boxes to be swapped during operation, increasing machine availability and productivity.
    • Protection: The digital input modules, like the CPU, are protected against extreme ambient conditions. They are coated with a 100% conformal coating, making them resistant to biologically, chemically, and physically active substances, condensation, frost, and corrosive gases.
    • Scalability: The modular design and wide variety of module characteristics offer improved scalability in terms of functionality and price.
    • Reliability: Regardless of the conditions, the system reliably records digital signals.
Additional Information

Support

Technical Data

Manuals / Links

Thông số kỹ thuật
FEATUREVALUE
Appendant operation agent (Ex ia)false
Supporting protocol for Foundation Fieldbusfalse
Number of HW-interfaces parallel0
Number of HW-interfaces other0
Permitted voltage at input30 V
Radio standard GSMfalse
Number of HW-interfaces RS-2320
Wall mounting/direct mountingfalse
Supporting protocol for SafetyBUS pfalse
Number of HW-interfaces serial TTY0
Rack-assembly possiblefalse
Fieldbus connection over separate bus coupler possibletrue
Number of HW-interfaces RS-4220
Appendant operation agent (Ex ib)false
Depth52 mm
Supporting protocol for AS-Interface Safety at Workfalse
IO link masterfalse
Supporting protocol for PROFIsafefalse
Digital inputs configurabletrue
Radio standard Bluetoothfalse
Width15 mm
Number of HW-interfaces USB0
Supporting protocol for ASIfalse
Radio standard UMTSfalse
Supporting protocol for TCP/IPfalse
Time delay at signal change0.015 ms
With optical interfacefalse
Degree of protection (IP)IP20
Radio standard WLAN 802.11false
Supporting protocol for PROFINET CBAfalse
Number of interfaces PROFINET0
Voltage type (supply voltage)DC
Supporting protocol for INTERBUS-Safetyfalse
Supporting protocol for Modbusfalse
Supporting protocol for SUCONETfalse
Height81 mm
Radio standard GPRSfalse
Suitable for safety functionsfalse
Type of voltage (input voltage)DC
Number of HW-interfaces industrial Ethernet0
Supporting protocol for DeviceNet Safetyfalse
Time delay at signal change15.15 ms
Number of digital outputs0
Number of HW-interfaces RS-4850
Supporting protocol for SERCOSfalse
Type of digital outputNone
Permitted voltage at input-30 V
Supply voltage DC28.8 V
Supporting protocol for other bus systemsfalse
Front built-in possiblefalse
Rail mounting possibletrue
Supporting protocol for CANfalse
Input current at signal 18 mA
Supply voltage DC20.4 V
Supporting protocol for EtherNet/IPfalse
Supporting protocol for KNXfalse
Supporting protocol for PROFINET IOfalse
Supporting protocol for DeviceNetfalse
Number of digital inputs4
System accessorytrue
Supporting protocol for PROFIBUSfalse
Supporting protocol for Data-Highwayfalse
Supporting protocol for LONfalse
Number of HW-interfaces wireless0
Supporting protocol for INTERBUSfalse
