Material ID: 6AG1193-6BP20-7DC0

SIPLUS ET 200SP BU20-P6+A2+4D based on 6ES7193-6BP20-0DC0 with conformal coating, -40…+60 °C, BU type C0, push-in terminals, with 2 AUX terminals, new load group, WxH: 20 mm x 117 mm
With SIMATIC ET 200SP, Siemens offers a multifunctional and distributed I/O system, which can be commissioned very simply due to its space-saving design.
It is approved for degree of protection IP20 and for installation in a compact control box.
The system ensures maximum flexibility because you can quickly and simply replace modules at any time due to the multi hot swapping feature.
SIMATIC ET 200SP also offers a wide range of different and fast communication methods.
With the integrated MultiFieldbus interface module IM155-6MF, you can use the optimum protocol for your application flexibly at any time because this function supports multiple Ethernet protocols.
Installation and service are simplified by a standardized identification system based on equipment labeling plates and color-coded connector assignments.
Siemens guarantees a future-proof investment due to integration of innovative and long-life automation products.
Consistent data availability, flexible use cases, and versatile integration options ensure optimum performance of ET 200 products.
The conformal coating protects SIPLUS BaseUnits against special environmental influences such as biologically, chemically and physically active substances.
Thus even your basic automation system is prepared for use in challenging environments.

Additional Information

Thông số kỹ thuật

FEATURE	VALUE
With pluggable modules, analogue I/O	false
Output voltage DC	0 V
Rack-assembly possible	false
Output voltage AC 50 Hz	0 V
Input voltage AC 60 Hz	230 V
Input voltage DC	0 V
Depth	35 mm
Type of output voltage	AC/DC
Suitable for safety functions	true
Front built-in possible	false
With pluggable modules, others	true
Output voltage DC	24 V
Width	20 mm
With pluggable modules, digital I/O	false
With integrated power supply	false
Wall mounting/direct mounting	false
Output voltage AC 50 Hz	230 V
Type of voltage (input voltage)	AC/DC
With pluggable modules, central modules	false
Input voltage DC	24 V
Output voltage AC 60 Hz	0 V
Appendant operation agent (Ex ib)	false
Rail mounting possible	true
System accessory	true
Appendant operation agent (Ex ia)	false
Input voltage AC 50 Hz	0 V
Number of slots	1
Output voltage AC 60 Hz	230 V
Input voltage AC 50 Hz	230 V
Input voltage AC 60 Hz	0 V
Height	117 mm
With pluggable modules, function and technology modules	false
With pluggable modules, communication modules	true
