Material ID: 6AG4021-0AA11-0AA0

SIMATIC IPC127E

The SIMATIC IPC127E is a compact industrial PC designed for reliable data recording, collection, processing, and sharing in the production environment. With its ultra-compact enclosure of just 0.3 liters volume, it can be easily integrated into control cabinets or directly on machines with minimal space requirements.

Technical Features:

Commercial Benefits:

The SIMATIC IPC127E offers the following commercial benefits:

Please note that the mounting brackets are not included with the product and must be ordered separately.

    • Processor: Atom E3930 (2C/2T)
    • RAM: 2 GB
    • Connectivity: 2x Ethernet RJ45, 2x USB3.0
    • Storage: 32 GB SSD
    • Operating System: Not included
    • Flexibility: The all-metal enclosure allows for flexible and maintenance-free use, even under harsh conditions.
    • IoT Gateway: It can be used as an IoT gateway between the Cloud or the company's IT level and production.
    • Quick Availability: Pre-configured versions ensure that the right product is available to users in a very short time.
Additional Information

Support

Technical Data

Manuals / Links

Thông số kỹ thuật
FEATUREVALUE
Processor clock rate1.3 GHz
Supporting protocol for Modbusfalse
Supporting protocol for SERCOSfalse
Number of HW-interfaces RS-4220
Supporting protocol for KNXfalse
Number of free PCI-slots0
Wall mounting/direct mountingtrue
Number of other free slots0
Supporting protocol for SafetyBUS pfalse
With sound cardfalse
Supporting protocol for Data-Highwayfalse
Radio standard UMTSfalse
Supporting protocol for DeviceNet Safetyfalse
Supporting protocol for PROFIBUSfalse
Degree of protection (IP)IP40
Supporting protocol for other bus systemstrue
Operating temperature55 °C
Supply voltage DC20.4 V
Suitable for safety functionsfalse
Number of free AGP-slots0
Number of HW-interfaces USB2
Supporting protocol for AS-Interface Safety at Workfalse
Supporting protocol for PROFINET CBAfalse
Supporting protocol for CANfalse
Rack-assembly possiblefalse
Radio standard Bluetoothfalse
Number of storage media bays0
Front built-in possiblefalse
Number of HW-interfaces wireless0
With graphic cardtrue
Number of HW-interfaces other0
Number of free PCMCIA-slots0
Supporting protocol for INTERBUS-Safetyfalse
Radio standard GSMfalse
Supporting protocol for PROFINET IOtrue
With optical drivefalse
Construction type housingBox
Supporting protocol for Foundation Fieldbusfalse
Height85 mm
Number of HW-interfaces serial TTY0
IO link masterfalse
Supporting protocol for PROFIsafefalse
Supporting protocol for EtherCATfalse
Max. main memory2000 MB
Operating temperature0 °C
Width85 mm
Supporting protocol for LONfalse
Number of HW-interfaces RS-4850
Depth41 mm
Number of HW-interfaces RS-2320
Supporting protocol for INTERBUSfalse
Supply voltage DC28.8 V
Supporting protocol for ASIfalse
Supporting protocol for EtherNet/IPfalse
Supporting protocol for DeviceNetfalse
With other storage mediafalse
Number of HW-interfaces industrial Ethernet2
Rail mounting possibletrue
With floppy disc drivefalse
Number of HW-interfaces parallel0
Radio standard GPRSfalse
Supporting protocol for SUCONETfalse
Radio standard WLAN 802.11false
Number of free ISA-slots0
Number of interfaces PROFINET2
