Material ID: 6AV6643-0CB01-1AX1
Technical Features:
Commercial Benefits:
- The new part, as of 01.01.2015, is blocked for delivery.
- Spare part can continue to be purchased as required, but price may deviate from new part.
- Further information under SIMATIC current entry ID: 109486162.
- For questions, the familiar contact persons are available to you.
- SIMATIC MP 277 8" Touch Multi Panel with retentive memory
- 7.5" TFT display
- 6 MB configuration memory, configurable with WinCC flexible 2005 Standard SP1
- Now only available as spare part.
Additional Information
Support | Technical Data | Manuals / Links |
Thông số kỹ thuật
| FEATURE | VALUE |
| Number of buttons with LED | 0 |
| Number of HW-interfaces parallel | 0 |
| Supporting protocol for CAN | false |
| Wall mounting/direct mounting | false |
| Supporting protocol for LON | false |
| Operating temperature | 50 °C |
| Degree of protection (IP), front side | IP65 |
| Number of pixels, vertical | 480 |
| Supply voltage DC | 20.4 V |
| Supporting protocol for PROFIsafe | false |
| Radio standard Bluetooth | false |
| Number of HW-interfaces wireless | 0 |
| Radio standard UMTS | false |
| Number of colours of the display | 65536 |
| Supporting protocol for INTERBUS | false |
| Supporting protocol for SERCOS | false |
| Supply voltage DC | 28.8 V |
| Screen diagonal | 7.5 inch |
| Supporting protocol for PROFIBUS | true |
| Number of HW-interfaces other | 1 |
| With message indication | true |
| With recipes | true |
| Supporting protocol for PROFINET IO | true |
| Built-in depth | 61 mm |
| Supporting protocol for INTERBUS-Safety | false |
| Voltage type (supply voltage) | DC |
| Supporting protocol for PROFINET CBA | false |
| Supporting protocol for Data-Highway | false |
| Supporting protocol for SafetyBUS p | false |
| Supporting protocol for AS-Interface Safety at Work | false |
| With printer output | true |
| Number of HW-interfaces serial TTY | 0 |
| Number of HW-interfaces RS-422 | 1 |
| With alpha numeric keyboard | true |
| Process value representation (output) possible | true |
| Type of display | TFT |
| Supporting protocol for KNX | false |
| Colour display | true |
| With SW interfaces | false |
| Useful project memory/user memory | 6000 kByte |
| Number of password levels | 50 |
| Supporting protocol for other bus systems | true |
| Height of the front | 190 mm |
| Width of the front | 250 mm |
| Supporting protocol for TCP/IP | true |
| Supporting protocol for EtherNet/IP | false |
| Number of interfaces PROFINET | 1 |
| Supporting protocol for DeviceNet | false |
| Supporting protocol for SUCONET | false |
| Radio standard GPRS | false |
| Additional software components, loadable | true |
| With numeric keyboard | true |
| Number of system buttons | 0 |
| Supporting protocol for ASI | false |
| Supporting protocol for Modbus | true |
| Number of function buttons, programmable | 0 |
| Rail mounting possible | false |
| Operating temperature | 0 °C |
| Supporting protocol for DeviceNet Safety | false |
| Number of grey-scales/blue-scales of display | 0 |
| Number of online languages | 16 |
| Number of HW-interfaces RS-485 | 1 |
| With message system (incl. buffer and confirmation) | true |
| Radio standard GSM | false |
| Radio standard WLAN 802.11 | false |
| Number of pixels, horizontal | 640 |
| Process default value (input) possible | true |
| Number of HW-interfaces RS-232 | 0 |
| Suitable for safety functions | false |
| Supporting protocol for Foundation Fieldbus | false |
| Number of HW-interfaces USB | 2 |
| Number of HW-interfaces industrial Ethernet | 1 |
| IO link master | false |
