Material ID: 6ES7131-4BB01-0AA0

Spare part

SIMATIC DP, 5 electronic modules for ET 200S, 2 DI Standard 24 V DC, 15 mm width, 5 units per packing unit

Technical Features

Commercial Benefits

    • Modularly scalable, distributed I/O system
    • Designed for installation in small control boxes near the machine
    • Modules can be plugged directly into an ET 200S IM with CPU functionality
    • Modules can be connected to a central controller via PROFINET or PROFIBUS
    • Expandable with up to 64 I/O modules
    • Comprehensive range of modules
    • Modules available with a wide variety of characteristics
    • Modules with standard functions (ST)
    • Modules with extended range of functions and diagnostics (HF High Feature/ HS High Speed)
    • Capability of swapping modules and terminal boxes during operation
    • Improved scalability in regard to functionality and price
    • Increased availability and productivity of the machine
    • Easy application with "hot swapping" capability
Additional Information

Support

Technical Data

Manuals / Links

Thông số kỹ thuật
FEATUREVALUE
Suitable for safety functionsfalse
Number of HW-interfaces USB0
Depth52 mm
With optical interfacefalse
Supporting protocol for PROFIBUSfalse
System accessorytrue
Supporting protocol for INTERBUSfalse
Supporting protocol for TCP/IPfalse
Input current at signal 17 mA
Time delay at signal change4.5 ms
Supporting protocol for SafetyBUS pfalse
Supporting protocol for Data-Highwayfalse
Radio standard Bluetoothfalse
Permitted voltage at input30 V
Radio standard GSMfalse
Supporting protocol for PROFINET IOfalse
Appendant operation agent (Ex ib)false
Supporting protocol for ASIfalse
Supply voltage DC20.4 V
Rail mounting possibletrue
Supporting protocol for PROFINET CBAfalse
Supporting protocol for EtherNet/IPfalse
Number of HW-interfaces other0
Number of HW-interfaces serial TTY0
Appendant operation agent (Ex ia)false
Width15 mm
Supporting protocol for AS-Interface Safety at Workfalse
Supporting protocol for PROFIsafefalse
Digital inputs configurabletrue
Permitted voltage at input-30 V
Number of HW-interfaces RS-4220
Degree of protection (IP)IP20
Supply voltage DC28.8 V
Front built-in possiblefalse
Type of digital outputNone
Supporting protocol for KNXfalse
Number of HW-interfaces wireless0
Supporting protocol for other bus systemsfalse
Supporting protocol for CANfalse
Supporting protocol for Foundation Fieldbusfalse
Number of interfaces PROFINET0
Supporting protocol for DeviceNetfalse
Voltage type (supply voltage)DC
Supporting protocol for INTERBUS-Safetyfalse
IO link masterfalse
Time delay at signal change2 ms
Radio standard UMTSfalse
Supporting protocol for SUCONETfalse
Type of voltage (input voltage)DC
Rack-assembly possiblefalse
Number of digital outputs0
Number of HW-interfaces RS-4850
Supporting protocol for Modbusfalse
Supporting protocol for SERCOSfalse
Number of HW-interfaces industrial Ethernet0
Number of digital inputs2
Supporting protocol for DeviceNet Safetyfalse
Supporting protocol for LONfalse
Radio standard WLAN 802.11false
Height81 mm
Wall mounting/direct mountingfalse
Fieldbus connection over separate bus coupler possibletrue
Number of HW-interfaces RS-2320
Number of HW-interfaces parallel0
Radio standard GPRSfalse
