Material ID: 6ES7132-4FB01-0AB0

Spare part

SIMATIC DP, 5 electronic modules for ET 200S, 2 DO 24...230 V AC 15 mm width, 5 units per packing unit

Technical Features

Commercial Benefits

    • Modularly scalable, distributed I/O system
    • Designed for installation in small control boxes near the machine
    • Modules can be plugged directly into an ET 200S IM with CPU functionality
    • Can be connected to a central controller via PROFINET or PROFIBUS
    • Expandable with up to 64 I/O modules
    • Comprehensive range of modules
    • Modules available with a wide variety of characteristics
    • Modules with standard functions (ST) and extended range of functions and diagnostics (HF High Feature/ HS High Speed)
    • Easy application with capability of swapping modules and terminal boxes during operation
    • Improved scalability in regard to functionality and price
    • Increased availability and productivity of the machine
    • Hot swapping capability
Additional Information

Support

Technical Data

Manuals / Links

Thông số kỹ thuật
FEATUREVALUE
Supporting protocol for DeviceNet Safetyfalse
Number of HW-interfaces industrial Ethernet0
Rail mounting possibletrue
Front built-in possiblefalse
Supporting protocol for TCP/IPfalse
Radio standard WLAN 802.11false
Number of digital inputs0
Number of HW-interfaces RS-4220
Fieldbus connection over separate bus coupler possibletrue
Rack-assembly possiblefalse
With optical interfacefalse
Number of HW-interfaces serial TTY0
Supporting protocol for SafetyBUS pfalse
Number of HW-interfaces USB0
Wall mounting/direct mountingfalse
Permitted voltage at output264 V
Supply voltage AC 60 Hz20.4 V
Digital outputs configurabletrue
Type of digital outputTriac
Radio standard UMTSfalse
Supporting protocol for other bus systemsfalse
Supporting protocol for ASIfalse
Supporting protocol for Modbusfalse
Appendant operation agent (Ex ib)false
Number of HW-interfaces other0
Supply voltage AC 60 Hz264 V
Radio standard GSMfalse
Appendant operation agent (Ex ia)false
Supporting protocol for INTERBUS-Safetyfalse
Width15 mm
Radio standard Bluetoothfalse
System accessorytrue
Supporting protocol for PROFINET CBAfalse
Degree of protection (IP)IP20
Number of HW-interfaces RS-2320
Supporting protocol for LONfalse
Supporting protocol for Data-Highwayfalse
Suitable for safety functionsfalse
Supporting protocol for PROFIsafefalse
Output current2 A
Permitted voltage at output0 V
Number of interfaces PROFINET0
Number of digital outputs2
Short-circuit protection, outputs availabletrue
Supporting protocol for Foundation Fieldbusfalse
Time delay at signal change15 ms
Supporting protocol for CANfalse
IO link masterfalse
Supply voltage AC 50 Hz264 V
Type of output voltageAC
Radio standard GPRSfalse
Supporting protocol for DeviceNetfalse
Supporting protocol for PROFINET IOfalse
Supporting protocol for SUCONETfalse
Supporting protocol for AS-Interface Safety at Workfalse
Depth52 mm
Number of HW-interfaces parallel0
Number of HW-interfaces RS-4850
Supply voltage AC 50 Hz20.4 V
Voltage type (supply voltage)AC
Supporting protocol for SERCOSfalse
Supporting protocol for KNXfalse
Supporting protocol for EtherNet/IPfalse
Height81 mm
Supporting protocol for INTERBUSfalse
Number of HW-interfaces wireless0
Supporting protocol for PROFIBUSfalse
