Material ID: 6ES7151-1CA00-1BL0
- ET 200S Compact, 32DI STD, 24 V DC, 3 ms
- Expandable by up to 12 modules of the ET 200S (no F modules) electronics block
- SIMATIC ET 200S is a modularly scalable, distributed I/O system
- Designed for installation in small control boxes near the machine
- Modules can be plugged directly into an ET 200S IM with CPU functionality
- Modules can also be connected to a central controller via PROFINET or PROFIBUS
- Can be expanded with up to 64 I/O modules in any combination
- Comprehensive range of modules available
- Modules with standard functions (ST) and extended range of functions and diagnostics (HF High Feature/ HS High Speed)
- Easy application with capability of swapping modules and terminal boxes during operation
- Increased availability and productivity due to "hot swapping"
Additional Information
Support | Technical Data | Manuals / Links |
Thông số kỹ thuật
| FEATURE | VALUE |
| Appendant operation agent (Ex ia) | false |
| Supporting protocol for EtherNet/IP | false |
| Supporting protocol for CAN | false |
| Radio standard Bluetooth | false |
| Supporting protocol for PROFINET IO | false |
| Supporting protocol for Modbus | false |
| Supporting protocol for ASI | false |
| Supporting protocol for other bus systems | false |
| Supporting protocol for KNX | false |
| Supporting protocol for DeviceNet | false |
| Supporting protocol for PROFINET CBA | false |
| Supporting protocol for Data-Highway | false |
| Digital inputs configurable | true |
| Supporting protocol for SafetyBUS p | false |
| Type of voltage (input voltage) | DC |
| Input current at signal 1 | 4 mA |
| Rail mounting possible | true |
| Rack-assembly possible | false |
| Supporting protocol for INTERBUS-Safety | false |
| Voltage type (supply voltage) | DC |
| Supporting protocol for PROFIBUS | true |
| Radio standard UMTS | false |
| Time delay at signal change | 1.2 ms |
| Permitted voltage at input | -3 V |
| Supporting protocol for AS-Interface Safety at Work | false |
| Type of digital output | None |
| Radio standard GSM | false |
| Radio standard WLAN 802.11 | false |
| Supporting protocol for INTERBUS | false |
| Number of digital inputs | 32 |
| Fieldbus connection over separate bus coupler possible | true |
| Width | 120 mm |
| IO link master | false |
| Supporting protocol for SERCOS | false |
| With optical interface | false |
| Supporting protocol for LON | false |
| Supply voltage DC | 20.4 V |
| Depth | 58 mm |
| Supporting protocol for PROFIsafe | false |
| Digital outputs configurable | true |
| Permitted voltage at input | 30 V |
| Front built-in possible | true |
| Supporting protocol for Foundation Fieldbus | false |
| Supporting protocol for DeviceNet Safety | false |
| Height | 81 mm |
| Wall mounting/direct mounting | true |
| Supply voltage DC | 28.8 V |
| Degree of protection (IP) | IP20 |
| Time delay at signal change | 4.8 ms |
| System accessory | true |
| Appendant operation agent (Ex ib) | false |
| Suitable for safety functions | false |
| Supporting protocol for SUCONET | false |
| Radio standard GPRS | false |
