Material ID: 6ES7212-1BB23-0XB8Spare Part - SIMATIC S7-200 CN

Spare Part - SIMATIC S7-200 CN

Technical Features

Commercial Benefits

The SIMATIC S7-200 CN is a micro PLC that offers maximum automation at minimum cost. It can be used for both simple controls and complex automation tasks.

    • Product: SIMATIC S7-200 CN
    • CPU: 222 Compact device
    • Power Supply: AC
    • Digital Inputs: 8 DI
    • Digital Outputs: 6 DO relay
    • Program Memory: 4 KB
    • Data Memory: 2 KB
    • Expandability: PROFIBUS DP
    • Approval: CE
Additional Information

Support

Technical Data

Manuals / Links





Thông số kỹ thuật
FEATUREVALUE
Redundancyfalse
Number of HW-interfaces industrial Ethernet0
Front built-in possibletrue
Radio standard UMTSfalse
Supporting protocol for PROFIBUSfalse
Number of HW-interfaces USB0
Supporting protocol for AS-Interface Safety at Workfalse
Supporting protocol for PROFINET IOfalse
Supporting protocol for EtherCATfalse
Radio standard GSMfalse
Supporting protocol for INTERBUSfalse
Radio standard Bluetoothfalse
Number of HW-interfaces RS-4851
Number of relay outputs6
Supporting protocol for PROFIsafefalse
Supporting protocol for TCP/IPfalse
ModelCompact
Voltage type (supply voltage)AC
Supporting protocol for DeviceNet Safetyfalse
Supporting protocol for ASIfalse
Explosion safety category for gasATEX gas-ex-protection, Cat. 3G
Supporting protocol for SafetyBUS pfalse
Height80 mm
Supporting protocol for INTERBUS-Safetyfalse
Number of interfaces PROFINET0
Number of HW-interfaces parallel0
Number of analogue inputs0
Supporting protocol for Data-Highwayfalse
Suitable for safety functionsfalse
Radio standard GPRSfalse
Supporting protocol for SUCONETfalse
Appendant operation agent (Ex ib)false
Number of HW-interfaces other0
Explosion safety category for dustNone
System accessorytrue
Supporting protocol for other bus systemstrue
Supporting protocol for PROFINET CBAfalse
Supporting protocol for Foundation Fieldbusfalse
Number of HW-interfaces RS-4220
Rack-assembly possiblefalse
Supporting protocol for CANfalse
Rail mounting possibletrue
Supply voltage AC 60 Hz85 V
Additional program memory possibletrue
Number of digital inputs8
Supporting protocol for DeviceNetfalse
Number of digital outputs6
Number of HW-interfaces RS-2320
Supporting protocol for KNXfalse
Supporting protocol for EtherNet/IPfalse
Appendant operation agent (Ex ia)false
Depth62 mm
Supporting protocol for LONfalse
With optical interfacefalse
Wall mounting/direct mountingtrue
Number of HW-interfaces wireless0
With displayfalse
Supporting protocol for SERCOSfalse
Supply voltage AC 60 Hz264 V
Processing time (1K, binary operation)0.22 ms
Number of analogue outputs0
Supply voltage AC 50 Hz264 V
Supporting protocol for Modbusfalse
Type of memoryEEPROM
Supply voltage AC 50 Hz85 V
Memory size6 kByte
Radio standard WLAN 802.11false
Width90 mm
IO link masterfalse
