Material ID: 6ES7222-1BD22-0XA0Product Description

Spare Part: SIMATIC S7-200

Technical Features:

Commercial Benefits:

Flexible adaptation of the control system.

    • Digital Output EM 222: Only compatible with S7-22X CPU
    • 4 DQ: 4-24 V DC
    • 5 A/channel source: Supplement to the integral I/O of the CPUs
Additional Information

Support

Technical Data

Manuals / Links



Thông số kỹ thuật
FEATUREVALUE
Suitable for safety functionsfalse
Supply voltage DC20.4 V
Digital outputs configurabletrue
Height80 mm
Output current5 A
Appendant operation agent (Ex ib)false
Type of output voltageDC
Supply voltage DC28.8 V
Number of digital inputs0
Short-circuit protection, outputs availablefalse
Width45 mm
Depth62 mm
Appendant operation agent (Ex ia)false
Voltage type (supply voltage)DC
Number of digital outputs4
Type of electric connectionScrew connection
Type of digital outputTransistor
Redundancytrue
Permitted voltage at output28.8 V
Time delay at signal change0.5 ms
Permitted voltage at output5 V
