Material ID: 6ES7222-1HD22-0XA0Product Description

Spare Part: SIMATIC S7-200 Digital Output EM 222

Technical Features:

Commercial Benefits:

The SIMATIC S7-200 Digital Output EM 222 is a spare part designed to supplement the integral I/O of the CPUs, allowing for flexible adaptation of the control system. With its 4 DQ (relay) outputs and a current rating of 10 A, it provides reliable and efficient control for various applications. The voltage range of 5-30 V DC or 5-250 V AC ensures compatibility with different power sources. This spare part is specifically designed for S7-22X CPU, making it a perfect fit for your control system needs.

    • Product: SIMATIC S7-200
    • Type: Digital Output EM 222
    • Compatibility: Only for S7-22X CPU
    • Number of Outputs: 4 DQ (relay)
    • Current Rating: 10 A
    • Voltage Range: 5-30 V DC or 5-250 V AC
Additional Information

Support

Technical Data

Manuals / Links





Thông số kỹ thuật
FEATUREVALUE
Voltage type (supply voltage)AC/DC
Permitted voltage at output12 V
Type of electric connectionScrew connection
Short-circuit protection, outputs availablefalse
Depth62 mm
Number of digital outputs4
Number of digital inputs0
Redundancytrue
Supply voltage AC 50 Hz12 V
Supply voltage AC 50 Hz250 V
Output current10 A
Time delay at signal change15 ms
Appendant operation agent (Ex ia)false
Width45 mm
Suitable for safety functionsfalse
Supply voltage DC20.4 V
Supply voltage AC 60 Hz250 V
Type of digital outputRelay
Supply voltage AC 60 Hz12 V
Type of output voltageAC/DC
Height80 mm
Digital outputs configurabletrue
Supply voltage DC28.8 V
Permitted voltage at output250 V
Appendant operation agent (Ex ib)false
