Material ID: 6ES7222-1HF22-0XA0Spare part SIMATIC S7-200
Spare part SIMATIC S7-200
Technical Features:
Commercial Benefits:
Order the SIMATIC S7-200 Spare part today to enhance your control system's capabilities and achieve greater flexibility in your operations.
- Digital output EM 222: Designed specifically for S7-22X CPU.
- 8 DA (relay outputs): Provides 8 relay outputs for flexible control system adaptation.
- 2A Supplement: Enhances the integral I/O of the CPUs.
- Flexible Adaptation: Allows for easy integration and customization of the control system.
- Enhanced Control: Provides additional relay outputs for improved control capabilities.
- S7-22X CPU Compatibility: Specifically designed to work seamlessly with S7-22X CPUs.
Additional Information
Support | Technical Data | Manuals / Links |
Thông số kỹ thuật
| FEATURE | VALUE |
| Digital outputs configurable | true |
| Supply voltage DC | 28.8 V |
| Permitted voltage at output | 250 V |
| Time delay at signal change | 10 ms |
| Appendant operation agent (Ex ia) | false |
| Redundancy | true |
| Number of digital inputs | 0 |
| Supply voltage AC 50 Hz | 250 V |
| Voltage type (supply voltage) | AC/DC |
| Permitted voltage at output | 5 V |
| Type of electric connection | Screw connection |
| Suitable for safety functions | false |
| Supply voltage AC 60 Hz | 250 V |
| Short-circuit protection, outputs available | false |
| Number of digital outputs | 8 |
| Width | 45 mm |
| Depth | 62 mm |
| Output current | 2 A |
| Supply voltage AC 60 Hz | 5 V |
| Type of digital output | Relay |
| Type of output voltage | AC/DC |
| Appendant operation agent (Ex ib) | false |
| Supply voltage AC 50 Hz | 5 V |
| Supply voltage DC | 20.4 V |
| Height | 80 mm |
