Material ID: 6ES7223-1BF22-0XA8

Spare Part: SIMATIC S7-200 CN, Digital I/O EM 223

This spare part is designed specifically for the S7-22X CPU and provides additional functionality for the control system.

Technical Features:

Commercial Benefits:

The SIMATIC S7-200 CN spare part offers the following benefits:

    • Compatibility: Only compatible with S7-22X CPU
    • Digital Inputs: 4
    • Digital Outputs: 4
    • Operating Voltage: 24 V DC
    • CE Approval: Yes
    • Flexible adaptation of the control system
    • Enhanced control capabilities
    • Improved system performance
Additional Information

Support

Technical Data

Manuals / Links





Thông số kỹ thuật
FEATUREVALUE
Time delay at signal change4.5 ms
Suitable for safety functionsfalse
Short-circuit protection, outputs availablefalse
Number of digital inputs4
Type of digital outputTransistor
Type of electric connectionScrew connection
Depth62 mm
Width46 mm
Explosion safety category for dustNone
Output current0.75 A
Supply voltage DC28.8 V
Redundancytrue
Appendant operation agent (Ex ia)false
Permitted voltage at output28.8 V
Number of digital outputs4
Permitted voltage at input30 V
Time delay at signal change3 ms
Voltage type (supply voltage)DC
Type of output voltageDC
Type of voltage (input voltage)DC
Supply voltage DC20.4 V
Permitted voltage at output0 V
Appendant operation agent (Ex ib)false
Height80 mm
Digital outputs configurabletrue
Digital inputs configurabletrue
Permitted voltage at input0 V
Input current at signal 14 mA
