Material ID: 6ES7223-1BH22-0XA0Spare part SIMATIC S7-200

Spare part SIMATIC S7-200

Technical Features

Commercial Benefits

Supplement to the integral I/O of the CPUs for flexible adaptation of the control system.

    • Digital I/O EM 223
    • Only for S7-22X CPU
    • 8 DI 24 V DC, Sink/Source
    • 8 DO 24 V DC
    • 0.75 A/channel source
Additional Information

Support

Technical Data

Manuals / Links



Thông số kỹ thuật
FEATUREVALUE
Supply voltage DC28.8 V
Appendant operation agent (Ex ib)false
Permitted voltage at output0 V
Permitted voltage at output28.8 V
Voltage type (supply voltage)DC
Time delay at signal change3 ms
Type of digital outputTransistor
Short-circuit protection, outputs availablefalse
Digital inputs configurabletrue
Permitted voltage at input0 V
Width71.2 mm
Type of voltage (input voltage)DC
Time delay at signal change4.5 ms
Output current0.75 A
Number of digital inputs8
Number of digital outputs8
Explosion safety category for dustNone
Type of output voltageDC
Appendant operation agent (Ex ia)false
Digital outputs configurabletrue
Depth62 mm
Type of electric connectionScrew connection
Suitable for safety functionsfalse
Input current at signal 14 mA
Height80 mm
Permitted voltage at input30 V
Redundancytrue
Supply voltage DC20.4 V
