Material ID: 6ES7223-1HF22-0XA0Spare part SIMATIC S7-200

Spare part SIMATIC S7-200

Technical Features

Commercial Benefits

This spare part is designed to supplement the integral I/O of the CPUs, allowing for flexible adaptation of the control system. With its digital inputs and outputs, it provides enhanced functionality and versatility to the S7-200 system.

    • Product: SIMATIC S7-200
    • Part Type: Digital I/O EM 223
    • Compatibility: Only for S7-22X CPU
    • Inputs: 4 DI (Digital Inputs)
    • Outputs: 4 DO (Digital Outputs) relay
    • Voltage: 5-30 V DC
    • Max Voltage: 250 V AC
Additional Information

Support

Technical Data

Manuals / Links





Thông số kỹ thuật
FEATUREVALUE
Number of digital outputs4
Digital inputs configurabletrue
Supply voltage DC30 V
Supply voltage AC 60 Hz250 V
Type of digital outputRelay
Suitable for safety functionsfalse
Appendant operation agent (Ex ib)false
Permitted voltage at input0 V
Height80 mm
Voltage type (supply voltage)AC/DC
Time delay at signal change4.5 ms
Supply voltage AC 50 Hz5 V
Supply voltage DC5 V
Digital outputs configurabletrue
Appendant operation agent (Ex ia)false
Permitted voltage at input30 V
Short-circuit protection, outputs availablefalse
Output current2 A
Explosion safety category for dustNone
Type of voltage (input voltage)AC/DC
Supply voltage AC 60 Hz5 V
Type of electric connectionScrew connection
Time delay at signal change3 ms
Redundancytrue
Input current at signal 14 mA
Depth62 mm
Permitted voltage at output250 V
Permitted voltage at output5 V
Number of digital inputs4
Type of output voltageAC/DC
Width46 mm
Supply voltage AC 50 Hz250 V
