Material ID: 6ES7223-1HF22-0XA8
Spare Part: SIMATIC S7-200 CN
The SIMATIC S7-200 CN is a spare part designed for use with the S7-22X CPU. It is a digital I/O EM 223 module that provides 4 DI (digital input) and 4 DO (digital output) relay channels.
Key Features:
The SIMATIC S7-200 CN is a supplement to the integral I/O of the CPUs, allowing for flexible adaptation of the control system.
Commercial Benefits:
- 4 DI/4 DO relay channels
- Input voltage range: 5-30 V DC
- Output voltage range: 5-30 V DC
- Maximum output voltage: 250 V AC
- CE approved
- Enhances the functionality of the S7-22X CPU
- Provides additional digital I/O capabilities
- Allows for flexible control system configuration
Additional Information
Support | Technical Data | Manuals / Links |
Thông số kỹ thuật
| FEATURE | VALUE |
| Time delay at signal change | 4.5 ms |
| Time delay at signal change | 3 ms |
| Supply voltage AC 50 Hz | 5 V |
| Type of electric connection | Screw connection |
| Number of digital outputs | 4 |
| Type of output voltage | AC/DC |
| Input current at signal 1 | 4 mA |
| Appendant operation agent (Ex ia) | false |
| Permitted voltage at input | 30 V |
| Digital inputs configurable | true |
| Supply voltage AC 50 Hz | 250 V |
| Appendant operation agent (Ex ib) | false |
| Supply voltage DC | 30 V |
| Permitted voltage at input | 0 V |
| Suitable for safety functions | false |
| Digital outputs configurable | true |
| Redundancy | true |
| Permitted voltage at output | 5 V |
| Explosion safety category for dust | None |
| Output current | 2 A |
| Number of digital inputs | 4 |
| Supply voltage DC | 5 V |
| Width | 46 mm |
| Voltage type (supply voltage) | AC/DC |
| Type of digital output | Relay |
| Supply voltage AC 60 Hz | 250 V |
| Short-circuit protection, outputs available | false |
| Depth | 62 mm |
| Height | 80 mm |
| Supply voltage AC 60 Hz | 5 V |
| Type of voltage (input voltage) | AC/DC |
| Permitted voltage at output | 250 V |
