Material ID: 6ES7241-1AA22-0XA0Spare part SIMATIC S7-200, Modem expansion module

Spare part SIMATIC S7-200, Modem expansion module

Technical Features:

Commercial Benefits:

Supplement to the integral I/O of the CPUs for flexible adaptation of the control system.

    • Analog modem
    • Supports PPI, MODBUS master/slave, SMS functionality
    • S7-200-to-S7-200 communication
    • Callback and password protection
Additional Information

Support

Technical Data

Manuals / Links





Thông số kỹ thuật
FEATUREVALUE
Radio standard Bluetoothfalse
Number of HW-interfaces USB0
With optical interfacefalse
Height80 mm
Supporting protocol for EtherNet/IPfalse
Radio standard WLAN 802.11false
Supporting protocol for PROFIBUSfalse
Supporting protocol for SERCOSfalse
Number of HW-interfaces industrial Ethernet0
Supporting protocol for SafetyBUS pfalse
Supporting protocol for PROFIsafefalse
Radio standard UMTSfalse
Number of interfaces PROFINET0
Number of HW-interfaces serial TTY0
Supporting protocol for INTERBUS-Safetyfalse
Type of data transmissionSerial
Number of HW-interfaces parallel0
Supporting protocol for KNXfalse
Number of HW-interfaces RS-2320
Supporting protocol for DeviceNetfalse
Supporting protocol for TCP/IPfalse
Supporting protocol for DeviceNet Safetyfalse
Appendant operation agent (Ex ib)false
Supporting protocol for Data-Highwayfalse
Explosion safety category for dustNone
Supporting protocol for EtherCATfalse
Number of HW-interfaces RS-4850
IO link masterfalse
Depth62 mm
Number of HW-interfaces wireless0
Supporting protocol for LONfalse
Supporting protocol for PROFINET CBAfalse
Suitable for safety functionsfalse
Supporting protocol for Foundation Fieldbusfalse
Supporting protocol for other bus systemstrue
Supporting protocol for INTERBUSfalse
Width71.2 mm
Radio standard GSMfalse
Supporting protocol for AS-Interface Safety at Workfalse
With potential separationtrue
Number of HW-interfaces RS-4220
Radio standard GPRSfalse
Supporting protocol for PROFINET IOfalse
Supporting protocol for SUCONETfalse
Redundancyfalse
Number of HW-interfaces other1
Supporting protocol for ASIfalse
Supporting protocol for Modbustrue
Appendant operation agent (Ex ia)false
