Material ID: 6ES7332-5TB10-0AB0

SIMATIC DP, HART analog output, SM 332, 2 AO, 0/4 - 20 mA HART

The SIMATIC DP, HART analog output, SM 332, 2 AO module is designed for use with the ET200M I/O system. It supports HART Rev. 5.0 and provides two analog output channels with a range of 0/4 - 20 mA.

Technical Features:

Commercial Benefits:

The ET200M is a modular and universally applicable I/O system for the control cabinet in IP20. It can be used as a central I/O on an S7-300 or in a distributed configuration on a PROFINET or PROFIBUS ET 200M interface module. The standardized setup of all modules simplifies logistics and stocking of spare parts. ET 200M can be used for both standard and safety-oriented applications.

Key Features:

    • Supports HART Rev. 5.0
    • 2 analog output channels
    • Output range: 0/4 - 20 mA
    • Modular and universally applicable I/O system
    • Supports up to 12 IO modules per station
    • Supports multi-channel signal modules and function modules
    • Supports S7-300 communications processors
    • Supports modules with extended user data, such as HART modules with HART auxiliary variables
    • FastConnect fast connection technology for easy wiring without stripping
Additional Information

Support

Technical Data

Manuals / Links





Thông số kỹ thuật
FEATUREVALUE
Supporting protocol for ASIfalse
Radio standard Bluetoothfalse
Radio standard UMTSfalse
Number of HW-interfaces parallel0
Supporting protocol for PROFINET CBAfalse
Supporting protocol for INTERBUS-Safetyfalse
Voltage type (supply voltage)DC
Supporting protocol for SafetyBUS pfalse
Suitable for safety functionsfalse
Output signal configurabletrue
Rack-assembly possibletrue
Number of HW-interfaces USB0
Number of HW-interfaces RS-4220
Supporting protocol for DeviceNet Safetyfalse
Supporting protocol for DeviceNetfalse
System accessorytrue
Number of analogue outputs2
Width40 mm
Supporting protocol for CANfalse
Degree of protection (IP)IP20
Radio standard GSMfalse
Height125 mm
Supporting protocol for Modbusfalse
Radio standard WLAN 802.11false
Number of analogue inputs0
Number of HW-interfaces other0
Number of HW-interfaces RS-4850
Supporting protocol for INTERBUSfalse
Resolution of the analogue outputs12 Bit
Number of HW-interfaces wireless0
Supporting protocol for KNXfalse
Supporting protocol for AS-Interface Safety at Workfalse
Supporting protocol for Foundation Fieldbusfalse
Analogue outputs configurabletrue
Wall mounting/direct mountingfalse
Supporting protocol for SUCONETfalse
Number of HW-interfaces serial TTY0
Number of HW-interfaces industrial Ethernet0
IO link masterfalse
Supporting protocol for PROFIsafefalse
Supporting protocol for TCP/IPfalse
Supporting protocol for LONfalse
Radio standard GPRSfalse
Supporting protocol for Data-Highwayfalse
Depth120 mm
Number of HW-interfaces RS-2320
Supporting protocol for EtherNet/IPfalse
Supporting protocol for SERCOSfalse
