Material ID: 6ES7647-0AA00-1YA2
- SIMATIC IoT2040 specifications:
- 2x 10/100 Mbit/s Ethernet RJ45
- 1x USB2.0, 1x USB client
- SD card slot
- 24 V DC industrial power supply
- The SIMATIC IOT2040 serves as a freely programmable platform for industrial IoT Gateway applications.
- It is based on Intel Quark processor technology, specifically developed for various Gateway applications.
- Key features of the SIMATIC IOT2040 Gateway include:
- Expandability
- Ability to be freely programmed in high-level languages
- Availability of multi-faceted packages in the Linux environment.
Additional Information
Support
Technical Data
Manuals / Links
Thông số kỹ thuật
| FEATURE | VALUE |
| Supporting protocol for LON | false |
| With sound card | false |
| Supply voltage DC | 9 V |
| Radio standard WLAN 802.11 | false |
| Number of HW-interfaces RS-232 | 2 |
| Rail mounting possible | true |
| Processor clock rate | 0.4 GHz |
| Number of HW-interfaces RS-485 | 2 |
| Rack-assembly possible | false |
| With other storage media | false |
| Supporting protocol for Data-Highway | false |
| With graphic card | false |
| Supporting protocol for Modbus | false |
| Supporting protocol for PROFINET IO | false |
| Supporting protocol for SERCOS | false |
| Radio standard UMTS | false |
| Number of storage media bays | 1 |
| Supporting protocol for PROFINET CBA | false |
| Degree of protection (IP) | IP20 |
| Operating temperature | 50 °C |
| Number of HW-interfaces RS-422 | 2 |
| Supporting protocol for INTERBUS-Safety | false |
| Supporting protocol for ASI | false |
| With floppy disc drive | false |
| Front built-in possible | false |
| Supply voltage DC | 36 V |
| Max. main memory | 1000 MB |
| Supporting protocol for other bus systems | false |
| Number of HW-interfaces industrial Ethernet | 2 |
| Supporting protocol for INTERBUS | false |
| Operating temperature | 0 °C |
| Suitable for safety functions | false |
| Radio standard GSM | false |
| Supporting protocol for EtherCAT | false |
| Supporting protocol for AS-Interface Safety at Work | false |
| Supporting protocol for PROFIsafe | false |
| With optical drive | false |
| Supporting protocol for CAN | false |
| IO link master | false |
| Supporting protocol for Foundation Fieldbus | false |
| Height | 90 mm |
| Supporting protocol for DeviceNet Safety | false |
| Wall mounting/direct mounting | true |
| Supporting protocol for SafetyBUS p | false |
| Supporting protocol for SUCONET | false |
| Supporting protocol for DeviceNet | false |
| Supporting protocol for PROFIBUS | false |
| With hard disc | false |
| Depth | 53 mm |
| Supporting protocol for KNX | false |
| Radio standard Bluetooth | false |
| Radio standard GPRS | false |
| Construction type housing | Box |
| Supporting protocol for EtherNet/IP | false |
| Number of HW-interfaces USB | 2 |
| Width | 144 mm |
