Material ID: 6ES7811-1CC08-0YA5

SIMATIC S7, S7-SCL V5.7 Floating License

This product is a floating license for 1 user of the SIMATIC S7-SCL V5.7 engineering software. It includes software and documentation on CD, as well as a license key on a USB flash drive. The license is classified as Class A and supports 5 languages (German, English, French, Spanish, Italian).

Technical Features:

Product Description:

The SIMATIC S7-SCL V5.7 is a powerful programming software designed for complex algorithm development, arithmetic functions, and data processing tasks. It combines language elements from high-level programming languages, such as serial loops, alternative branches, and jump lists, with PLC-specific language expansions. These expansions include addressing inputs and outputs, as well as starting and querying times and counters.

S7-SCL corresponds to the textual high-level language ST (Structured Text) defined in the standard IEC 61131-3 and meets the base level and reusability level requirements according to PLCopen. It is an essential component of STEP 7 Professional (TIA Portal).

Commercial Benefits:

With the SIMATIC S7-SCL V5.7 floating license, you can streamline your programming tasks and achieve optimal performance in your automation projects.

    • Compatible with STEP 7 V5.7
    • Executable in Windows Server 2016, Windows Server 2019, 2022, Windows 10 / 11 Professional, Windows 10 Enterprise
    • Reference hardware: S7-300/400, C7
    • Efficient programming of complex algorithms and arithmetic functions
    • Enhanced data processing capabilities
    • Supports multiple languages for international usability
    • Flexible compatibility with various Windows operating systems
    • Compatible with S7-300/400 and C7 reference hardware
Additional Information

Support

Technical Data

Manuals / Links





Thông số kỹ thuật
FEATUREVALUE
With editor for programming language ST (structured text)false
Suitable for operating system Windows Vistafalse
Suitable for operating system Windows 8false
Integrated application configuration functiontrue
With editor for programming language SFC (Sequential Function Chart)false
Integrated evaluation functiontrue
Integrated configuration functiontrue
Integrated analysis functiontrue
Suitable for operating system Windows CEfalse
Integrated position functionfalse
Suitable for operating system Windows 9xfalse
Technology function integratedfalse
Suitable for safety functionsfalse
Maintenance function integratedfalse
With editor for programming language Flowchartfalse
Integrated motion functionfalse
With editor for programming language LD (Ladder Diagram)false
Suitable for other operating systemtrue
Suitable for operating system Windows 7false
According to IEC 1131-3 (DIN EN 61131-3)true
Suitable for operating system Windows 2003 Serverfalse
Suitable for operating system Linuxfalse
Suitable for operating system Windows NTfalse
Simulation function integratedfalse
Integrated diagnosis functiontrue
Integrated communication functiontrue
Suitable for operating system Windows 2000false
Put into operation function integratedfalse
Suitable for operating system Windows MEfalse
With editor for programming language FBD (Function Block Diagram)false
Suitable for operating system Windows XPfalse
Integrated data detection functiontrue
With editor for manufacturer specific programming languagetrue
With editor for programming language IL (Instruction List)false
