Material ID: 6ES7833-1FC02-0YE5

SIMATIC S7, F-programming tool S7 Distributed Safety V5.4

Upgrade from V5.X to V5.4

Floating license for 1 user

E-SW, SW and documentation on DVD

Class A

3 languages (de, en, fr)

Executable in Windows 7 SP1, Windows 10 Professional, Windows 10 Enterprise, Windows Server 2008 R2 SP1, Windows Server 2012 R2, Windows Server 2016

64-bit operating system required

STEP 7 V5.5 SP1 or higher

Ref, -HW S7-300F/400F/WinAC F

Engineering of safety-oriented applications in connection with STEP 7 V5.x

Not only can the safety-oriented and standard program be run on the same CPU, but they can also be created using the same engineering tools.

The creation of a safety-oriented program component is done using the standard STEP 7 languages LAD and FBD as well as the option package S7 Distributed Safety.

S7 Distributed Safety provides support through a command library with TÜV-approved blocks (e.g. emergency stop, two-hand control, muting, door monitoring).

Own blocks can also be generated. This greatly facilitates reproducibility or the expansion of existing projects.

Programming safety-oriented applications with controllers of the new generation

For programming safety-oriented applications with controllers of the new generation, the S7-1200F, S7-1500F, ET 200SP F-CPU and S7-1500 Software Controller F, you need the engineering software STEP 7 Safety (TIA Portal).

You can, of course, also use STEP 7 Safety (TIA Portal) to program the fail-safe systems S7-300F, S7-400F, and SIMATIC WinAC RTX F.

    Additional Information

    Support

    Technical Data

    Manuals / Links





    Thông số kỹ thuật
    FEATUREVALUE
    Integrated application configuration functiontrue
    Suitable for operating system Windows NTfalse
    Integrated position functionfalse
    Suitable for operating system Linuxfalse
    Suitable for operating system Windows 8false
    Maintenance function integratedfalse
    Suitable for operating system Windows MEfalse
    With editor for programming language ST (structured text)false
    Integrated evaluation functiontrue
    Suitable for operating system Windows 2000true
    According to IEC 1131-3 (DIN EN 61131-3)true
    Suitable for other operating systemfalse
    Integrated diagnosis functiontrue
    Integrated communication functiontrue
    Suitable for operating system Windows Vistafalse
    Integrated analysis functiontrue
    Suitable for operating system Windows 2003 Servertrue
    With editor for manufacturer specific programming languagetrue
    Integrated data detection functiontrue
    With editor for programming language LD (Ladder Diagram)true
    Suitable for operating system Windows 7true
    Technology function integratedfalse
    Suitable for safety functionstrue
    Simulation function integratedtrue
    With editor for programming language FBD (Function Block Diagram)true
    Put into operation function integratedtrue
    With editor for programming language Flowchartfalse
    Suitable for operating system Windows CEfalse
    Integrated motion functiontrue
    With editor for programming language SFC (Sequential Function Chart)false
    With editor for programming language IL (Instruction List)true
    Integrated configuration functiontrue
    Suitable for operating system Windows XPtrue
    Suitable for operating system Windows 9xfalse
