Material ID: 6XV1830-0EN20
  • PROFIBUS FC Standard, bus cable 2-wire, shielded, special configuration for Quick assembly 20 m.
  • SIMATIC NETCablesPROFIBUS FC Standard Cable GP
  • Standard bus cable specially designed for fast installation.
  • The double shield makes it especially suitable for routing through industrial areas with strong electromagnetic fields.
  • Time is saved thanks to easy and quick on-site installation.
  • Reliable shield contact and strain relief as well as efficient EMC shielding.
  • Network is not sensitive to interferences due to shielded, twisted-pair cable.
  • System-wide grounding concept can be implemented using the external shield of the bus cable and the grounding terminals on the bus terminal.
  • Silicone-free, therefore suitable for use in the automotive industry (for example on paint lines).
  • Easy length measurement thanks to printed meter marking.
Additional Information

Support

Technical Data

Manuals / Links

Thông số kỹ thuật
FEATUREVALUE
Stranding elementPairs
Permitted cable outer temperature during assembling/handling75 °C
Min. permitted bending radius, moving application/free movement75 mm
CategoryOther
Permitted cable outer temperature after assembling without vibration-40 °C
Screen over stranding elementNone
Number of stranding elements1
Colour outer sheathPurple
Core identificationColour
Number of cores2
Screen over strandingFoil + braiding
Min. permitted bending radius, moving application with forced guidance75 mm
Diameter conductor0.65 mm
Suitable for underground installationfalse
Outer diameter approx.8 mm
Min. permitted bending radius, stationary application/permanent installation75 mm
Conductor surfaceBare
Permitted cable outer temperature during assembling/handling-40 °C
Reaction-to-fire according to EN 13501-6: ClassEca
Permitted cable outer temperature after assembling without vibration75 °C
